PRECISION & POWER RESISTORS

When you can’t afford to take chances—take charge

When you are developing a design with no tolerance for failure—whether the application will perform on the road, in the air, or the furthest reaches of space—our line of ISA-PLAN® and ISA-WELD® resistors deliver unequaled performance. Discover how you can meet the highest requirements in temperature coefficient of resistance (TCR), thermal EMF, long-term stability, inductance and load capacity.

SURFACE MOUNT ASSEMBLY


Our products set new standards for low-ohmic resistors, becoming the global benchmark in this field. Our physically optimized current sensors (“shunts”) provide a range of unique benefits:

  • Retain specified tolerances over the entire temperature range
  • Retain specified tolerances under full power load
  • Retain specified tolerances throughout the entire operating life cycle

BUS BAR MOUNTING


Free-up your designs from concerns about stability and assembly with our bus bar mounting for high current applications:

  • Up to 50 Watts permanent power
  • Made from electron-beam welded composite
  • Heavy Copper terminals
  • High permanent and pulse power rating

HYBRID MOUNTING


Our bondable resistors (for high-power applications) are durable and offer wide flexibility in design—with excellent heat dissipation and high load capacity. Design features extensive bonding on a conductive DBC substrate.

  • Permanent power up to 20 W
  • Constant currents up to 140 A
  • Mounting: Reflow-, IR-soldering or bonding on substrate
  • 4-terminal-connection technology
  • Conductive DBC-/IMS-soldering assembly
  • Nickel-plated/Au-plated bond pads
  • Low resistance values

PCB AND HEAT SINK MOUNTING


We offer a wide variety of heat sink mounting designs that suit your most demanding applications—including high-precision resistors for laboratory applications. Several intelligent housing-shapes offering easy heat sink mounting are available.

  • Permanent Power up to 10 W
  • Constant Current up to 70 A
  • 4 Terminal connection

BRAKING RESISTORS / PRECHARGE RESISTORS


Our UL-listed components are designed to support high loads (up to 3100 Watts) and high pulse rates (up to 31kW for 5 sec). Their compact size saves you space and make them easy to mount.

  • Rugged Extruded Aluminum Housing
  • Flying leads and tab terminals available
  • IP 54 protection type
  • Customizable

AVIATION AND AEROSPACE


Whenever highest reliability, precision and longevity are required, there is no way around the low-ohmic precision and power resistors from Isabellenhütte.

It is not without reason that we have been supplying measuring resistors to the aerospace industry for more than ten years.

We always meet the toughest quality standards and consider our customers’ individual requirements (ESCC 4001). In addition, the SnPb-tinned contacts avoid the forming of whisker and thus short circuits in many applications.

  • Power rating up to 3 W (SMD mounting)
  • Constant currents up to 30 A
  • Sizes: 2010, 2512, 2817, 4723
  • Very high pulse power rating
  • Very good long-term stability
  • Low TCR

TYPICAL APPLICATIONS


Aerospace

Long-term safety and reliability for the most sophisticated—and demanding—applications.
Learn More >>

Automotive

Fit more technology into limited spaces within cost and performance parameters.
Learn More >>

Industrial

From factory automation, to performance-driven consumer goods, we support bold innovation.
Learn More >>

Medical

Supporting life-saving advances with compact technology and long-term reliability.
Learn More >>
