PRECISION MEASUREMENT
DC METER FOR CHARGING INFRASTRUCTURE (IEM-DCC)

Shunt-based DC energy reference meter
for power classes up to 500 kW
A smart solution for demanding applications such as public EV DC fast charging, the IEM-DCC-500 supports current ranges up to 500 A and voltage ranges up to 1,000 V. Shunt measurement technology allows for a compact design and an SML-based communication protocol supports features like billing systems allocation for public stations.
- Current measurement range: 500 A (nominal), up to 600 A (maximum)
- Voltage range up to 1,000V (maximum)
- Operating temperature range from -13° to 167°F (-25 to +75°C)
- Housing protection class IP30, sealable and flame-protected (UL94-V0)
- Integrated TFT display with different display levels on photodiode input
- SML-based communication protocol with the meter modes EDL 40 and EDL 40 ++
- Supports cable-loss compensation
Model | DC Sensing Range | Max Sensing Range | Max DC Voltage | Supply Voltage | Temp Range | Accuracy Class | Interface | IP Rating | Product Details |
---|---|---|---|---|---|---|---|---|---|
IEM-DCC | 500A | 600A | 1000V | 10V-48V | -25C to +75C | A and B | RS485 | IP30 | View More |
